7E- 14 DIFFERENTIALS

29) Apply the specified tightening torque to the screws fixing

the lids of the rolling elements of the differential box.

Tightening torque screws fixing rolling element lids :

8 ÷ 8.5 Kg-m (80 ÷ 85 Nm)

30) Assemble the brake ensemble (2), formed by the elastic pin

and the fixing plate.

31) Assemble the differential group reversing the dismantling

order and taking account the specified tightening torque in

the complemenatry task.
