7E- 16 DIFFERENTIALS
Assembly
1) Carry out the assembly of the rear differential reversing the
dismantling order, and take into account the specified
tightening torque and those specified in the complementary
task.
Tightening torque:
• Nut fixing flange:
14 ÷ 20 Kg-m (140 ÷ 200 Nm)
• Screws fixing crown:
12 ÷ 14 Kg-m (120 ÷ 140 Nm)
• Screws for rolling element lids:
12 ÷ 14 Kg-m (120 ÷ 140 Nm)
• Screws fixing half sumps of differential box:
5 ÷ 6 Kg-m (50 ÷ 60 Nm)
Resistance to engaging pinion turning (without oil
seal):
12.3 ÷ 14.3 Kg-m (123 ÷ 143 Nm)
Revision
1) Revise all the rear differential components in the same way
you did in the front differential (see7E-6).
