Shimadzu GC-2010 Plus User Manual

16 Special Functions
16.6 GC Configuration
249
GC-2010 Plus
Q APC gas
If you select the APC gas for the flow signal selection to display the screen shown in Fig. 16.6.11.
16.6.7.6 Signal offset
When you select [Gain etc.] (PF menu) from the signal setup main screen, the Gain and
offset screen shown in Fig. 16.6.12 appears. Set the offset and the the detector signal
gain here.
Select [Sig. Ch] (PF menu), to set the gain and the offset for any signal other than
defector signals (such as temperature or pressure). In addition, you can set the time
constant and the zero adjustment of the signal for each channel.
Fig. 16.6.11 APC gas signal setup screen
Fig. 16.6.12 Detector signal gain and offset screen
The currently set channel No.
is displayed.
Select an item to be output
from each area.

Shimadzu GC-2010 Plus Specifications

General

Type	Gas Chromatograph
Model	GC-2010 Plus
Manufacturer	Shimadzu
Maximum Temperature Ramp Rate	120 °C/min
Detector Options	FID, TCD, ECD, FPD, NPD, MS
Electronic Flow Control (EFC)	Yes
Data Sampling Rate	Up to 250 Hz
Column Oven Temperature Range	Ambient +5°C to 450°C
Maximum Oven Heating Rate	120 °C/min
Injection Port	Split/Splitless, PTV
Display	LCD
