17 Printing
17.1 Printing
276
GC-2010 Plus
17.1.2.6 Log
From each screen of the GC operation log, the analysis log, the parameter log, the error
log and the diagnostic log, press [Print] (PF menu) to print the parameters displayed on
the screen.
For the analysis log, only the list screen is printed. The contents of the detailed analysis
screen are not printed.
For example, press [Print] (PF menu) from the error log screen, to obtain the following
printed results.
NOTE The log items are printed in chronological order, starting from the oldest.
Fig. 17.1.6
17.1.2.7 Diagnosis results
Press [Print] (PF menu) from the detailed results screen of the standard diagnosis to
print a report similar to the ones shown below.
The date, the version No. and the installation status, which are not displayed on the
screen, are also printed.
Fig. 17.1.7
- GC ERROT LOG -
TIME OCCURED CODE ERROR MESSAGE (VALUE)
200.05.16 14:21 [E1020] DET1 sensor down error (530.00)
200.05.16 14:27 [E0031] INJ-DET2 A/D error
200.05.16 14:27 [E0032] AUX1-AUX3 A/D error
200.05.16 14:27 [E0011] CAR1 AFC PCB error (7.00)
200.05.16 14:27 [E0030] COL A/D error
200.05.16 14:27 [E0001] DC5 V range error (8.43)
200.05.16 14:27 [E0002] DC24 V range error (20.34)
200.05.16 14:27 [E0034] Battery voltage error (0.26)
200.05.16 14:27 [E0005] Room temp range error (84.27)
200.05.16 14:27 [E1019] INJ1 sensor down error (530.00)
200.05.16 14:27 [E1018] COL sensor down error (530.00)
200.05.16 14:27 [E1020] DET1 sensor down error (530.00)
200.05.16 14:28 [E0031] INJ1-DET2 A/D error
200.05.16 14:28 [E0032] AUX1-AUX3 A/D error
200.05.16 14:28 [E0011] CAR1 AFC PCB error (7.00)
- GC DIAGNOSIS REPORT -
DATE 2000.06.15 14:35
GC SERIAL NUMBER “C11123380069SM”
ROM VERSION 0.0202
DET#1 FID WIDE
DET#2 NON
DET#3 NON
DET#4 NON
CAR1 AFC+PU
CAR2 NON
CAR3 NON
DET APC 1 APC(3Ch)
DET APC 2 NON
DET APC 3 NON
DET APC 4 NON
TEST RESULT Not Good
- INJ1 Septum Counter -
Threshold 100
Count value 0
Judgement Good
