19 Troubleshooting
19.2 Error Messages
323
GC-2010 Plus
This message appears when the program execution time exceeds the maximum allowable
value (9999.99 min). Change the program so that its total execution time does not exceed
“9999.99 min”.
The program continues running after this error occurs, and stops at 9999.99 min.
Temperature control errors
This message appears when large heat loss is occurring. The oven door may be open, or
the insulation may not be in place.
If the column over door is open, close it and select “Reset Error”.
If the insulation has been disturbed, replace the insulation, and then restart the system..
This message appears when the maximum temperature limit has been exceeded. Change
the maximam limit temperature if necessary.
Temperature sensor errors
When one of these messages appear, the temperature sensor may have failed.
The sensor cannot be used. Replace or repair it. Turn off the system, and contact your
Shimadzu representative.
Unstable temperature with CRG
This message appears when the column over or the INJ2 cannot be cooled down because
the column oven door remains open or insufficient coolant (also for INJ2) is preventing the
oven CRG from cooling.
If the column oven door is open, close it and select “Reset Error”.
Turn off the system, replace the coolant, and then restart the system.
Code Message CS Note
4302 Program time is over No
4303 Clean up time is over No
4304 Pre-run prog. time is over No
Code Message CS Note
1001 Heat is escaping Yes
Code Message CS Note
1002-1009 xxx temp exceed the limit Yes
xxx=COL, INJ1, DET1,
INJ2, DET2, AUX3,
AUX4, AUX5
Code Message CS Note
1010-1017 xxx sensor is short circuit Yes
xxx=COL, INJ1, DET1,
INJ2, DET2, AUX3,
AUX4, AUX5
1018-1025 xxx sensor is down Yes
1026-1033 xxx sensor is error Yes
Code Message CS Note
1034 COL CRG cannot be controlled Yes
1035 INJ2 CRG cannot be controlled Yes
To Next Page
