19 Troubleshooting
19.2 Error Messages
324
GC-2010 Plus
Overheat
An error may have occurred in the temperature control circuit.
Turn off the system, and contact your Shimadzu representative.
Relay/heater control errors
An error may have occurred in the control circuit. Turn off the system, and contact your
Shimadzu representative.
This message appears when the Detector temperature setting value is smaller than that of
the Oven.
If this message appears, change the setting value of the Detector temperature.
If set the setting of Protection against contamination to “No”, need not to change the setting
value of the Detector temperature. (Refer to 16.6.4.3)
Pressure/flow rate control errors
The prressure cannot reach the set value. Check whether gas is supplied and whether gas
is leaking from connections.
NOTE Gas leaks may be occurring in several locations.
(Example) If the purge flow rate is too low,the message “Purge leaks” may appear. If the carrier gas is
also leaking, the ESC or TFC error message may not be displayed first.
Code Message CS Note
1036 Overheat is sensed Yes
Overheat detected by
thermocouple
1037-1044 xxx temp controller broken Yes
xxx=COL, INJ1, DET1,
INJ2, DET2, AUX3,
AUX4, AUX5
Code Message CS Note
1045 COL relay error No
1046 INJ1-DET2 relay error No
1047 AUX3-AUX5 relay error No
1048 Heater controller error No
Code Message CS Note
1049-1052 DET#n set temp is low No n=1-4
Code Message CS Note
2005-2007 CARx purge leaks Yes x=1-3
2014, 2017
2020, 2023
DetAPC n makeup gas leaks Yes
n=1-4
2015, 2018
2021, 2024
DetAPC n hydrogen leaks Yes
2016, 2018
2022, 2025
DetAPC n air leaks Yes
2026-2043 APC y leaks Yes y=1-18
To Next Page
