19 Troubleshooting
19.2 Error Messages
325
GC-2010 Plus
Pressure/flow rate control errors (valve leak error)
Gas is flowing even though the set value is 0 kPa (or ml/min).
If gases are supplied, an AFC/APC valve error may have occurred.
Turn off the system, and contact your Shimadzu representative.
Abnormal component operation
Verify whether a continuous supply of gas is available at the required pressure.
If there is no problem in the gas supply, the control system, such as the APC, may have
failed.
Turn off the system, and contact your Shimadzu representative.
This message appears when the temperature control starts without carrier gas control.
If this message appears, set the setting of the flow controller to “On” or remove the flow con-
troller from the line configuration.
Code Message CS Note
2048-2050 CARx purge valve leaks Yes x=1-3
2057, 2060
2063, 2066
DetAPC n makeup valve leaks Yes
n=1-4
2058, 2061
2064, 2067
DetAPC n hydrogen valve leaks Yes
2059, 2062
2065, 2068
DetAPC n air valve leaks Yes
2069-2086 APC y valve leaks Yes y=1-18
2132, 2133 CAR m AFC valve leaks Yes m=1-2
Code Message CS Note
2091-2093 CARx purge is out of control Yes x=1-3
2100, 2103
2106, 2109
DetAPCn makeup gas is out of control Yes
n=1-4
2101, 2104
2107, 2110
DetAPCn hydrogen is out of control Yes
2102, 2105
2108, 2111
DetAPCn air is out of control Yes
2112-2129 APCy is out of control Yes y=1-18
2130, 2131 CARm AFC leaks Yes
m=1-2
2134-2137 CARm AFC is out of control Yes
2138-2140 CARx prim is out of range No x=1-3
Code Message CS Note
2141, 2142 CARm is not controlled No m=1-2
To Next Page
