CONVEYOR ENHANCEMENTS
Lubricate CheckMate™ Turn Shaft Bearing Blocks
6-118 Aquastorm™ Series Options Guide Rev. 1
6
Tools and Materials Use the following tools and materials:
• Magna-Lube™ G high temperature lubricant
• Phillips screwdriver
Procedure Use the following steps to access the front conveyor grease points:
1. Shut down Aquastorm™ system operation.
2. Ensure system power is Off.
3. Remove the rear system panel to access the rear prewash section.
4. Use a phillips screwdriver to remove the CheckMate™ motor cover.
5. Use the high temperature lubricant and grease the drive shaft grease point.
6. Replace the CheckMate™ motor cover and secure it in place with a phillips
screwdriver.
7. Replace the rear system panel.
