Speedline Technologies ELECTROVERT Aquastorm - Drain Tank and Check Low Level Sensor

DETERGENT INJECTION
Drain Tank and Check Low Level Sensor
9-184 Aquastorm™ Series Options Guide Rev. 1
9
Drain Tank and Check Low Level Sensor
Introduction During routine quarterly maintenance drain the saponifier from the detergent
injection storage tank and clean the tank and float switch.
Safety To ensure personal safety and avoid equipment damage observe the following:
CAUTION
Arrange for two (2) people to move or lift the storage tank to avoid possible
injury.
ATTENTION
If any damage is discovered, discontinue use and contact Electrovert technical
support.
Photographs Figure 9–10 shows the detergent injection storage tank. Figure 9–11 shows the
float switch assembly located at the rear of the tank.
Figure 9–10
Figure 9–11
Detergent Injection
Storage Tank Access
Door and Handle
Float
Switch
End of
Tank
Float Switch
Assembly
