DRYER MODIFICATIONS
Functional Description
15-284 Aquastorm™ Series Options Guide Rev. 1
15
Functional Description
Introduction The Side Connector Airknife Technology (SCAT) option package installs only in
dryer module #1 or add-on dryer module #3. The SCAT adjusts horizontally and
vertically to offer additional drying to the sides of a PCB (Printed Circuit Board) as
it moves along the conveyor.
Diagram Figure 15–9 shows dryer #1 configured with front and rear mounted SCAT
airknives.
Figure 15–9
