DETERGENT INJECTION
Clean Vinyl Tubing and Strainer
9-182 Aquastorm™ Series Options Guide Rev. 1
9
Clean Vinyl Tubing and Strainer
Introduction The detergent injection system requires quarterly maintenance unless saponifier is
changed or PCB cleaning quality declines.
Safety To ensure personal safety and avoid equipment damage observe the following:
ATTENTION
If any damage to any parts of the detergent injection nozzle, electrical system,
detergent storage tank, or storage tank float switch sensor is noted, contact
Electrovert technical support for repair or replacement.
Materials required Use the following materials for cleaning:
• Clean facility water
• Compressed air
Photograph Figure 9–9 displays the detergent injector, tubing, strainer, and connections.
Figure 9–9
Vinyl Tubing
Injector Inlet
Venturi Housing
Metering Screw
Stainless Steel Strainer
To Next Page
