OPTIONS AND TECHNICAL DATA
CAT Package
2-40 Aquastorm™ Series Options Guide Rev. 1
2
CAT Package
Introduction The Compressed Air Technology (CAT) option package mounts in all standard or
add-on dryer modules and provides additional drying capabilities in product with
deep cavities. Shop air connects to an air regulator mounted on the top rear of
the machine above the dryer modules. The mounting box contains an On/Off
button to initiate CAT processing. The CAT option is compatible with systems
where the optional CheckMate™ hold down conveyor is installed.
Air Requirements The CAT option requires standard shop compressed air at up to 241 kPa (35 psi).
Other Requirements The photocell option is required when the CAT option is installed.
Photograph Figure 2–17 shows the CAT adjustable nozzles and indicates different adjustment
steps.
Figure 2–17
CAT Adjustable
Nozzles
Dryer Blower
Section Rear
Curtains Between
Final Rinse and Dryer #1
Bulkhead
