DETERGENT INJECTION
Overview
9-168 Aquastorm™ Series Options Guide Rev. 1
9
Section A:
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Functional Description
Overview
Introduction The detergent injection option is only available for use on Aquastorm 200™
systems and operates best when the chemical isolation module is installed and
active.
Safety To ensure personal safety and avoid equipment damage observe the following:
ATTENTION
A factory trained field service representative must install detergent injection
systems.
Photograph Figure 9–1 shows the Aquastorm 200™ rear prewash and wash sections with the
detergent injection tank installed.
Figure 9–1
Detergent
Storage Tank
Vinyl Tubing
Installed in
Wash Inlet
Plumbing
Wash Tank
Low Level Sensor Cable
Detergent Injector System Electric Box
Detergent Injector
Assembly Installed
in Wash Line
Detergent Delivery Vinyl Tubing
Storage Tank
