Speedline Technologies ELECTROVERT Aquastorm - Section A. Inlet and Exit Conveyor Extensions; Overview

CONVEYOR ENHANCEMENTS
Overview
6-78 Aquastorm™ Series Options Guide Rev. 1
6
Section A:
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Inlet and Exit Conveyor Extensions
Overview
Introduction This section describes the angle adjust inlet extension and the extended exit
conveyor options.
In this section Refer to the following information:
Topic See Page
Functional Description 6 – 79
Inlet Conveyor Extension Installation 6 – 80
Exit Conveyor Extension Installation 6 – 83
Conveyor Wire Belt Set Up 6 – 86
Software Configuration 6 – 90
