HURRICANE JETS™ AND PUMPS
Functional Description
2-9317-600-00-0 Aquastorm™ Series Options Guide 11-225
Section E:
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Pumps
Functional Description
Introduction The water pump circulates water in the recirculating wash cycle on all systems
and the recirculating rinse cycle on Aquastorm 200™ systems. Water pump
upgrades increase water circulation and flow to ensure maximum cleaning
efficiency and pressure when the optional Hurricane Jet™ nozzle configurations
are installed.
• Single Hurricane Jet™ nozzles require a 10 HP water pump upgrade
• Dual Hurricane Jet™ nozzles require 15 HP water pump upgrade
Photograph Figure 11–24 shows a standard 5 HP pump connected to standard Vee Jet
nozzles on the left and a 10 HP upgrade pump connected to a single Hurricane
Jet™ option on the right.
Figure 11–24
Standard 5 HP
10 HP Upgrade
