BLOWER ENHANCEMENTS
Set Point Configuration
16-318 Aquastorm™ Series Options Guide Rev. 1
16
Set Point Configuration
Introduction The blower fail detect unit ships from the factory with the necessary
configuration functions preset. Configuration information is provided In the
unlikely event the unit requires reconfiguration.
Safety To ensure personal safety and avoid equipment damage observe the following:
Electrical Hazard
Risk of Electric Shock – Electrical current used can kill. DO NOT TOUCH live
electrical components inside the electrical enclosure.
Tools required Use the following tools to perform configuration:
• Flat head screwdriver
Photograph Figure 16–11 shows a close up view of the blower fail detect unit and identifies
the unit controls.
Figure 16–11
Set Point
Status
Closed
Status
Open
Set Screw
