DRYER MODIFICATIONS
Software Configuration
15-292 Aquastorm™ Series Options Guide Rev. 1
15
Software Configuration
Introduction The Electrovert service person performing installation or the system administrator
should configure the machine.
After installing an IR heater, the system software must be configured to recognize
it. The configuration screens interface with the system software. System
software may lock up if the operator attempts to configure items that do not exist
on the system.
Diagram Figure 15–14 shows Configuration Screen #2:
Figure 15–14
Navigating menu
screens
To access and navigate the configuration screens:
• Press the Menu key on the LDC Interface key pad to access the main configu-
ration screen.
• Scroll between the configuration screens by pressing the page up or page
down keys.
• Move the underline screen cursor to a specific option by pressing the up or
down arrow keys. Press the Enter key to toggle between selection choices.
RESISTIVITY NONE
DRYER #2 BLOWER ONLY
DRYER #3 NO
DRYER #4 NO
SUMP TANK STANDARD
SUMP TANK #2 NONE
C/I SPRAY PUMP
C/I BLOWER YES
