BLOWER ENHANCEMENTS
Access Blower Motor Belt
2-9317-600-00-0 Aquastorm™ Series Options Guide 16-321
Access Blower Motor Belt
Introduction Use the following information to access and replace the blower motor belt.
Safety To ensure personal safety and avoid equipment damage, observe the following:
CAUTION
A qualified electrician or Electrovert service person should perform motor rotation
check and verify motor electrical connections.
Diagram Figure 16–12 shows a typical blower assembly diagram.
Figure 16–12
Spring Load
Belt Tensioner
Blower Pulley
Head Assembly
Motor
Motor Pulley
Belt
Blower Motor
Power Box
Rotation
Motor
Direction
Arrow
Bolt for
Socket Wrench
To Next Page
