FLOW METERS
Review Flow Meter View Menu
2-9317-600-00-0 Aquastorm™ Series Options Guide 7-139
Review Flow Meter View Menu
Introduction The flow meter ships from the factory with the necessary calibration functions
preset. Meter calibration information is provided In the unlikely event the meter
requires recalibration.
Safety To ensure personal safety and avoid equipment damage observe the following:
ATTENTION
A qualified maintenance person with plumbing experience should perform flow
meter configuration.
Diagrams Figure 7–4 shows a close up view of the flow mete.
Figure 7–4
Up Arrow
Down Arrow
Quick Release
Clamp
Screen
Mounting
Pipe
