OPTIONS AND TECHNICAL DATA
Photocell Sensors
2-28 Aquastorm™ Series Options Guide Rev. 1
2
Photocell Sensors
Introduction The photocell provides an automatic stand by mode for PCB detection on the inlet
conveyor extension or as a board jam alert on the CheckMate™ exit end conveyor.
Photographs Figure 2–7 shows a close up view of the photocell reflector and sensor emitter
units.
Figure 2–7
Sensor UnitReflector Unit
