Speedline Technologies ELECTROVERT Aquastorm - Hurricane Jet Nozzles and Pumps

OPTIONS AND TECHNICAL DATA
Enhanced Cleaning
2-34 Aquastorm™ Series Options Guide Rev. 1
2
Section K:
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Hurricane Jet™ Nozzles and Pumps
Enhanced Cleaning
Introduction The wash module on all Aquastorm™ systems or rinse module on Aquastorm
200™ systems can be enhanced with a single or Dual Hurricane Jet™ performance
kit. The Hurricane Jet™ nozzle provides a vertical sheet of water that enhances
PCB (Printed Circuit Board) cleaning around and under components. The single
Hurricane Jet™ nozzle option requires the standard 5 HP pump be replaced with a
10 HP pump. The dual Hurricane Jet™ nozzle requires a 15 HP pump upgrade.
Photographs Figure 2–12 shows the single Hurricane Jet™ nozzle spray and dual Hurricane
Jet™ nozzle spray.
Figure 2–12
Single Hurricane Jet™ Nozzle
Dual Upper Hurricane Jet™ Spray
Dual Lower Hurricane Jet™ Spray
