Speedline Technologies ELECTROVERT Aquastorm - Flow Meters

. . . . .
OPTIONS AND TECHNICAL DATA
Water Flow
2-9317-600-00-0 Aquastorm™ Series Options Guide 2-29
Section G:
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Flow Meters
Water Flow
Introduction Flow meters assist in maintaining a constant full level flow balance throughout
the Aquastorm system. Two (2) flow meters are available. One (1) installs in the
prewash module plumbing. The other installs in the final rinse module plumbing.
Photograph Figure 2–8 shows the prewash flow meter installed in an Aquastorm™ system:
Figure 2–8
