Connect Wire Belt Links
2-9317-600-00-0 Aquastorm™ Series Options Guide 6-129
Connect Wire Belt Links
Introduction Install the wire belt so the flat portion runs in the direction indicated below. The
closed end of the loop goes toward the direction of travel. The large arrows
indicate the movement of the splicing link between steps.
Diagrams The following graphics, courtesy of the Wire Belt Company of America provide
additional connection information.
Limit splicing link bending to the straight portions of the strand rather than the
preformed bent areas.
