OPTIONS AND TECHNICAL DATA
Aquastorm 200™ Systems
2-9317-600-00-0 Aquastorm™ Series Options Guide 2-21
Aquastorm 200™ Systems
Introduction Refer to the electrical specifications provided to ensure adequate power is
installed at the site where the system is installed.
Table The following table lists the power requirements for an Aquastorm 200™ system.
Specification Type Specification
Standard Electrical
Requirements
Normal operating power is
80-85% of maximum power
required, depending on process
parameters and operation load
for the product being run.
Standard voltage: 460 VAC, 3 phase, 60 Hz. (214 Amps Max.)
Other voltages: 380 VAC, 3 phase, 50 Hz. (259 Max. FLA)
Single point electrical drop
Integrated system disconnect
Not available for 220 VAC systems
Lock out/Tag out capability
All loads configured with over current protection
Full Load Calculation FLA (Full Load Amps)
Total Machine kVA x 1000
Amps Required
=
(1.732) (Machine Voltage)
Aquastorm 200™ Modules
Module Total Power Module Total Power
Controls 3 kVA
Wash Module Add-On Single Dryer (Opt.)
Heaters (2 @ 16 kVA) 32.kVA 7.5 HP Blower (Std.) 7.7 kVA
5 HP Pump (Std.) 5 kVA 10 HP Blower (Opt.) 10 kVA
10 HP Pump (Opt.) 10 kVA 15 HP Blower (Opt.) 14.6 kVA
15 HP Pump (Opt.) 14.6 kVA
Chemical Isolation Level 1 (Opt.) Add-On Dual Dryer (Opt.)
7.5 HP Blower (Std.) 7.7 kVA Dual Dryer Module #1
Enhanced Chemical Isolation Lvl 2 (Opt.) 7.5 HP Blower (Std.) 7.7 kVA
7.5 HP Blower (Std.) 7.7 kVA 10 HP Blower (Opt.) 10 kVA
Enhanced Chemical Isolation Lvl 3 (Opt.) 15 HP Blower (Opt.) 14.6 kVA
7.5 HP Blower (Std.) 7.7 kVA Dual Dryer Module #2
Single 16 kVA Heater (Std.) 16 kVA 7.5 HP Blower (Std.) 7.7 kVA
Rinse Module 10 HP Blower (Opt.) 10 kVA
Heaters (2 @ 16 kVA) 32 kVA IR Heaters (Opt.) 3.6 kVA
5 HP Pump (Std.) 5 kVA Drain Options
10 HP Pump (Opt.) 10 kVA ¾ HP Sump Pump (Opt.) 0.83 kVA
15 HP Pump (Opt.) 14.6 kVA 2 HP Sump Pump (Opt.) 2.2 kVA
Dryer Module #1
7.5 HP Blower (Std.) 7.7 kVA
10 HP Blower (Opt.) 10 kVA
15 HP Blower (Opt.) 14.6 kVA
Dryer Module #2
7.5 HP Blower (Std.) 7.7 kVA
10 HP Blower (Opt.) 10 kVA
IR Heaters (Opt.) 3.6 kVA
Optional Electrical Connection
Integrated system disconnect
not available for 220 VAC.
Other voltage: 220 VAC, 3 phase, 60 Hz. (428 Max. FLA)
Electrical Codes/Compliance Underwriters Laboratory (UL)
Listed for factory automation on 440 V and 220 V machines
European Customers
CE Compliance Package
Electrical Standard for Industrial Machinery, NFPA 70
