LIGHTED STATUS TOWER
Software Configuration
5-68 Aquastorm™ Series Options Guide Rev. 1
5
Software Configuration
Introduction The Electrovert service person performing installation or the system administrator
should configure the machine.
After installing a lighted status tower, the system software must be configured to
recognize it. The configuration screens interface with the system software.
System software may lock up if the operator attempts to configure items that do
not exist on the system.
Diagram Displayed below is Configuration Screen #3:
Figure 5–2
Navigating the menu
screens
To access and navigate the configuration screens:
• Press the Menu key on the LDC Interface key pad to access the main configu-
ration screen.
• Scroll between the configuration screens by pressing the page up or page
down keys.
• Move the underline screen cursor to a specific option by pressing the up or
down arrow keys. Press the Enter key to toggle between selection choices.
Configuration
Procedure
Configure the light tower as follows
1. Press the menu key on the LCD interface keypad to access configuration
screen #1.
2. Press the page down key twice to display configuration screen #3.
3. Press the enter key to toggle to YES and indicate the light tower is installed.
4. Press the enter key to accept the configuration.
5. Press the Menu key to accept the changes.
6. Result: The update screen displays and the system returns to the main menu.
7. Begin system operation. For detailed information refer to the Aquastorm 200™
or Aquastorm 100™ Operation Manual.
LIGHT TOWER YES
BOARD_TRACKING BLOWER OFF
SAPONIFIER YES
UPS NO
CONV PITCH 3/8
KEYSWITCH DISABLE
BLOWER FAIL YES
SYS_CLOCK SET
To Next Page
