FLOW METERS
Overview
7-134 Aquastorm™ Series Options Guide Rev. 1
7
Section A:
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Functional Description
Overview
Introduction Flow meters assist in maintaining a constant full level flow balance throughout
the Aquastorm™ system. Two (2) flow meters are available. One (1) installs in the
prewash module plumbing. The other installs in the final rinse module plumbing.
Safety To ensure personal safety and avoid equipment damage, observe the following:
CAUTION
Flow meter calibration can affect normal system operation. DO NOT change
factory settings unless flow meter function is impaired. A qualified maintenance
person with plumbing experience should perform flow meter configuration.
ATTENTION
Any significant fluctuation in the external water source flow pressure or process
change can affect system balance.
Photograph Figure 7–1 shows one (1) flow meter installed in the prewash section of an
Aquastorm™ system.
Figure 7–1
Prewash
Flow Meter
Upper Spray Bar
Flow Control Valve
Lower Spray Bar
Flow Control Valve
Full Closed Position
Full Open Position
To Next Page
