LIGHTED STATUS TOWER
Connect the Light Tower
2-9317-600-00-0 Aquastorm™ Series Options Guide 5-65
Section B:
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Installation
Connect the Light Tower
Introduction When the Aquastorm™ system ships with a light tower option installed, the
lighted status tower is separated from its mounting bracket, wrapped in bubble
pack, and taped securely to the top of the machine cabinet.
Safety To ensure personal safety and avoid equipment damage observe the following:
CAUTION
When setting the light tower in place, ensure the electrical cables housed in the
base of the light tower shaft are not pinched or damaged.
Electrical Hazard
An electrical engineer must install the light tower.
Tools • Phillips head screwdriver
Shut Down/Start Up
Procedure
Use the following steps prepare for the procedure.
1. Shut down Aquastorm system operation.
2. Ensure system power is Off.
3. Perform Lock Out/Tag Out steps. See Lock-Out Tag-Out on page 10.
4. Perform procedure.
5. Remove Lock Out-Tag Out tags. See Lock-Out Tag-Out on page 10.
6. Begin system operation. For detailed information refer to the Aquastorm 200™
or Aquastorm 100™ Programming and Operation Manual.
