PH MONITOR
Software Configuration
8-158 Aquastorm™ Series Options Guide Rev. 1
8
Software Configuration
Overview
Introduction The Electrovert service person performing installation or the system administrator
should configure the machine.
After installing a pH monitor, the system software must be configured to
recognize it. The configuration screens interface with the system software.
System software may lock up if the operator attempts to configure items that do
not exist on the system.
Diagram Displayed below is Configuration Screen #1:
Figure 8–2
Navigating the menu
screens
To access and navigate the configuration screens:
• Press the Menu key on the LDC Interface key pad to access the main configu-
ration screen.
• Scroll between the configuration screens by pressing the page up or page
down keys.
• Move the underline screen cursor to a specific option by pressing the up or
down arrow keys. Press the Enter key to toggle between selection choices.
MODEL 200
TEMP_UNITS F
SPEED_UNITS F/min
CHECKMATE NO
pH MONITOR NO
WASH PUMP HURRICANE
RINSE PUMP HURRICANE
CONFIGURATION
To Next Page
