HURRICANE JETS™ AND PUMPS
Overview
11-202 Aquastorm™ Series Options Guide Rev. 1
11
Section B:
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Installation Overview
Overview
Introduction Wash module nozzle plumbing mounts in the rear wash section of the machine.
Rinse module nozzle plumbing mounts in the rear rinse section of the Aquastorm
200™.
Safety To ensure personal safety and avoid equipment damage observe the following:
ATTENTION
A factory trained field service representative must install Hurricane Jet™ nozzles
and pump upgrades.
Installation package • Plumbing prints
• Installation instructions
•Hurricane Jet™ Assembly
• Pump upgrade kit
• Mounting brackets and hardware
• Additional plumbing lines and elbows
• Water flow On/Off ball valve
• Replacement water pump assembly
• Replacement filter assembly
• Teflon gaskets
Tools and materials • 5/32 in. Allen wrench
• Phillips screwdriver
• 8 mm hex head wrench
• 0.020 feeler gauge
