HURRICANE JETS™ AND PUMPS
Overview
2-9317-600-00-0 Aquastorm™ Series Options Guide 11-201
Photographs Figure 11–3 shows the dual Hurricane Jet™ nozzle locations and operation.
Figure 11–3
Single Hurricane Jet™ The wash module on all Aquastorm™ systems or rinse module on Aquastorm
200™ systems can be enhanced with a Hurricane Jet™ performance kit. The
Hurricane Jet™ manifold mounts between the standard four (4) upper spray bars.
The performance kit includes a 10 hp pump to replace the standard 5 hp pump
and a 378 L/min (100 gpm) filter to replace the standard 189 L/min (50 gpm)
filter.
Dual Hurricane Jet™ The wash module on all Aquastorm™ systems or rinse module on Aquastorm
200™ systems can be further enhanced with a Dual Hurricane Jet™ performance
kit. The two (2) Hurricane Jet™ manifolds mount opposite each other. One (1)
between the standard four (4) upper spray bars and the other between the
standard four (4) lower spray bars. The performance kit includes a 15 hp pump to
replace the standard 5 hp pump and a 578 L/min (150 gpm) filter to replace the
standard 189 L/min (50 gpm) filter.
Spray Bars
Upper Hurricane Jet™ Nozzle
Lower Hurricane Jet™ Nozzle
Upper Hurricane Jet™ Spray Action
Lower Hurricane Jet™ Spray Action
