LIGHTED STATUS TOWER
Parts and Functions
2-9317-600-00-0 Aquastorm™ Series Options Guide 5-69
Parts and Functions
Introduction The light tower lenses flash or illuminate to indicate the system operating status.
Table The following table describes the lighted status tower major parts and their
functions
The flashes when and illuminates when
Red light • Emergency Stop
• Power Off with an alarm condition
• Low Level condition in the Wash,
Rinse, or Chemical Isolation tank
• High Level condition in the Wash,
Chemical Isolation, or Rinse tank
• Low Temperature or Temperature
Deviation in the Wash, Chemical
Isolation, or Rinse tanks, and
Radiant Heater
• High Temperature condition in the
Wash, Rinse, or Chemical Isolation
tanks, or Dryer section
• High Level in Optional Sump Pump
Holding Tank
• Checkmate error, i.e. a conveyor
jam or a PWA detected in the upper
photocell
NA
Amber light • Red Status Light is Off
• System is warming up and the
conveyor is coming up to speed
• Red Status Light
Off
• Power is applied to
the system, system
is up to set point
temperatures, but
the Power Off
control red indicator
is illuminated
Green light • System operating in the board
tracking mode (photocell operation)
• Green Power On
indicator illuminated
•Conveyor On -
forward or reverse
• All temperatures
reached setpoint
•Amber Status
Tower Light Off
• Red Status Tower
Light Off
