CONVEYOR ENHANCEMENTS
Software Configuration
2-9317-600-00-0 Aquastorm™ Series Options Guide 6-97
Software Configuration
Introduction The Electrovert service person performing installation or the system administrator
should configure the machine.
After installing a CheckMate™ hold down conveyor, the system software must be
configured to recognize it. The configuration screens interface with the system
software. System software may lock up if the operator attempts to configure
items that do not exist on the system.
Diagram Figure 6–11 shows Configuration Screen #1 and Figure 6–12 shows the Main
Screen:
Figure 6–11
Figure 6–12
Navigating the menu
screens
To access and navigate the configuration screens:
• Press the Menu key on the LDC Interface key pad to access the main configu-
ration screen.
• Scroll between the configuration screens by pressing the page up or page
down keys.
• Move the underline screen cursor to a specific option by pressing the up or
down arrow keys. Press the Enter key to toggle between selection choices.
MODEL 200
TEMP_UNITS F
SPEED_UNITS F/min
CHECKMATE NO
pH MONITOR NO
WASH PUMP HURRICANE
RINSE PUMP HURRICANE
CONFIGURATION
AQUASTORM 200
MODULE SETP ACTUAL
CONVEYOR 7.7 F/min 0.0
WASH 145F 103
RINSE 150F 119
DRYER_1 F 74
DRYER_2 F 72
PW_FLOW 17.0 LPM
To Next Page
