CONVEYOR ENHANCEMENTS
Exit Conveyor Extension Installation
2-9317-600-00-0 Aquastorm™ Series Options Guide 6-83
Exit Conveyor Extension Installation
Introduction Prior to shipment the exit conveyor extension is removed and packed separately
in the shipping container.
Safety To ensure personal safety and avoid equipment damage observe the following:
Electrical Hazard
High Voltage can shock, burn, or cause death. Use extreme caution when
connecting electrical wires. These procedures must be performed only by an
authorized electrician, electrical engineer, or service technician.
Entanglement Hazard
All moving parts of the Aquastorm system, including pulleys, sprockets, chains,
and the conveyor represent potential hazards. Use caution and avoid having
hands or fingers caught in any moving mechanism. Long hair, jewelry, and other
parts of loose attire could be caught in moving mechanisms and cause injury.
Photograph Figure 6–4 shows the front exit end electric wire jumper strip.
Figure 6–4
Bolt On
Sound
Enclosure
Main
Power
Switch
Machine
Front
Storage
Cabinet
Electrical
Jumper
Strip
Electric
Wire
Cover
To Next Page
