BAG FILTERS
Remove/Replace Bag Filter
2-9317-600-00-0 Aquastorm™ Series Options Guide 13-245
Remove/Replace Bag Filter
Introduction The felt bag filter is not reusable. During routine preventive maintenance
approximately 150 to 200 hours of machine operation, check the bag filter.
Remove and replace the filter if it appears damaged or is excessively dirty.
Safety To ensure personal safety and avoid equipment damage observe the following:
CAUTION
Failure to properly latch and tighten the bag filter lid in place can result in damage
to the equipment and excessive water leakage.
Materials required Use the following materials for cleaning:
• Replacement bag filter
• O-ring gasket, if necessary
Photograph Figure 13–3 displays the bag filter inside the mesh basket.
Figure 13–3
Bag Filter Handles
Mesh Basket Handle
O-ring
Gasket
To Next Page
