CONVEYOR ENHANCEMENTS
Maintenance Schedule
2-9317-600-00-0 Aquastorm™ Series Options Guide 6-109
Section D:
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Preventive Maintenance
Maintenance Schedule
Introduction A strong preventive maintenance program is the best method to cut costs,
increase system reliability, and enhance productivity. The time used for cleaning,
inspecting, and servicing ensures consistent production quality and increases the
extended service life of the machine.
Safety To ensure personal safety and avoid equipment damage observe the following:
CAUTION
Qualified maintenance staff should perform the following steps. If any damage to
the wire belt, conveyor motors, pulleys, or conveyor rail is noted, contact
Electrovert Customer Service.
Maintenance Schedule Refer to the following maintenance schedule to ensure proper operation.
List of procedures Use the following procedures to complete conveyor preventive maintenance
Daily Maintenance — Every eight (8) hours of Operation
Cleaning Procedure Reference
Inspect for bent links and proper tensioning
Clean photocell sensor and reflector
Quarterly Maintenance — Every 480 hours of Operation
Lubricate conveyor bearing blocks
Lubricate CheckMate™ bearing blocks
Yearly Maintenance — Every 1920 hours of Operation
Lubricate conveyor drive chain
Lubricate CheckMate™ drive chain
Topic Page
Inspect Standard Conveyor Belt 6 – 110
Lubricate Conveyor Turn Shaft Bearing Blocks 6 – 111
Lubricate Conveyor Drive Shaft Bearing Blocks 6 – 113
Lubricate Conveyor Drive Chain 6 – 115
Lubricate CheckMate™ Turn Shaft Bearing Blocks 6 – 117
Lubricate CheckMate™ Drive Shaft Bearing Blocks 6 – 119
Lubricate CheckMate™ Drive Chain 6 – 121
Clean Photocell 6 – 122
