SUMP PUMP
Software Configuration
2-9317-600-00-0 Aquastorm™ Series Options Guide 17-335
Software Configuration
Introduction The Electrovert service person performing installation or the system administrator
should configure the machine.
After installing a sump pump, the system software must be configured to
recognize it. The configuration screens interface with the system software.
System software may lock up if the operator attempts to configure items that do
not exist on the system.
Diagram
Displayed below is Configuration Screen #2:
Figure 17–3
Navigating the menu
screens
To access and navigate the configuration screens:
• Press the Menu key on the LDC Interface key pad to access the main configu-
ration screen.
• Scroll between the configuration screens by pressing the page up or page
down keys.
• Move the underline screen cursor to a specific option by pressing the up or
down arrow keys. Press the Enter key to toggle between selection choices.
MODEL 200
TEMP_UNITS F
SPEED_UNITS F/min
CHECKMATE NO
pH MONITOR NO
WASH PUMP HURRICANE
RINSE PUMP HURRICANE
CONFIGURATION
RESISTIVITY NONE
DRYER #2 BLOWER ONLY
DRYER #3 NO
DRYER #4 NO
SUMP TANK STANDARD
SUMP TANK #2 NONE
C/I SPRAY PUMP
C/I BLOWER YES
To Next Page
