Lubricate CheckMate™ Turn Shaft Bearing Blocks
2-9317-600-00-0 Aquastorm™ Series Options Guide 6-117
Lubricate CheckMate™ Turn Shaft Bearing Blocks
Introduction The CheckMate™ conveyor drive motor is located in the rear prewash section at
the entrance end of all Aquastorm™ systems.The CheckMate™ conveyor turn
shaft contains bearing blocks. Each bearing block contains grease fittings that
require quarterly maintenance.
Photographs Figure 6–26 shows the rear prewash section and CheckMate™ motor cover
location. Figure 6–27 shows the CheckMate™ conveyor turn shaft side view and
indicates the grease point.
Figure 6–26
Figure 6–27
Rear Prewash
Section
CheckMate™
Motor Cover
CheckMate™ Motor
with Cover Removed
Grease Point
