DRYER MODIFICATIONS
Software Configuration
2-9317-600-00-0 Aquastorm™ Series Options Guide 15-293
Configuration
Procedure
Configure the radiant heater option as follows:
1. Press the page down key once to display configuration screen #2.
2. Press the enter key to toggle to Blower + IR to indicate Dryer #2 contains a
radiant heater.
3. If add-on Dryer #4 is installed and configured with an IR heater, press the
enter key to display Blower + IR to indicate the radiant heater option is
installed.
4. Press the enter key to accept the configuration.
5. Press the Menu key to accept the changes.
6. Result: The update screen displays and the system returns to the main menu.
Diagrams Figure 15–15 displays Configuration Screen #4. Figure 15–16 shows the alarm
process screen.
Figure 15–15
Figure 15–16
ALARM_PROCESS SET
WATCH_DOG TEST
PRE_WASH_FLOW YES
FINAL_RINSE_FLOW YES
FLOW_UNITS GPM
GAS_HEAT_WASH NO
GAS_HEAT_RINSE NO
MACH_LEN_PCT 50
ALARM BAND ACTION REALARM
CONV 1.0 FPM WARNING 05 MIN
WASH 10 F SHUTDOWN 05 MIN
CHEM 10 F IGNORE 05 MIN
RINSE 10 F SHUTDOWN 05 MIN
BLWR 10F WARNING 05 MIN
SAPON SHUTDOWN 05 MIN
BLWR_FAIL SHUTDOWN 05 MIN
To Next Page
