BLOWER ENHANCEMENTS
Set Point Configuration
2-9317-600-00-0 Aquastorm™ Series Options Guide 16-319
Shut Down/Start Up
Procedure
Use the following steps prepare for the procedure.
1. Shut down Aquastorm system operation.
2. Ensure system power is Off.
3. Perform Lock Out/Tag Out steps. See Lock-Out Tag-Out on page 10.
4. Perform procedure.
5. Remove Lock Out-Tag Out tags. See Lock-Out Tag-Out on page 10.
6. Begin system operation. For detailed information refer to the Aquastorm 200™
or Aquastorm 100™ Programming and Operation Manual.
Procedure This procedure sets the primary configuration for the blower fail detect unit.
When active, this alarm setup takes precedence. Use the following steps to set
under current status indicator for belt loss, fan, and blower status:
1. Turn the set point screw clockwise until the status Closed LED turns Off and
the status Open LED turns On.
2. Turn the set point screw counterclockwise until the status Open LED turns
Off and the status Closed LED turns On.
3. Turn the set point screw ¼ turn counter clockwise.
4. The sensor is now calibrated to recognize current flows below normal full load
amps.
Procedure The procedure sets a secondary configuration for the blower fail detect unit.
Standard Aquastorm™ operations do not use this configuration. It is provided for
reference only. Use the following steps to set over current status indicator for a
locked blower rotor:
1. Turn the set point screw counterclockwise until the status until the status
Open LED turns Off and the status Closed LED turns On.
2. Turn the set point screw clockwise until the status closed LED turns Off and
the status Open LED turns On.
3. Turn the set point screw clockwise ¼ turn.
4. The sensor is now calibrated to recognize current flows above normal full load
amps.
