FLOW METERS
Review Flow Meter Options Menu
7-142 Aquastorm™ Series Options Guide Rev. 1
7
Menu Functions Table The following table identifies flow meter options menu functions.
Procedure Review the Options menu as follows:
1. Press the flow meter Up and Down arrows at the same time.
2. Hold for five (5) seconds to display the Options menu.
3. To access the option settings, press the Up arrow three (3) times then press
the Down arrow one (1) time.
4. Press the Up or Down arrows to locate the decimal settings.
5. Press the Right arrow to view the current settings.
6. Use the Up and Down arrows to set the decimal places at one (1) digit.
7. Press and hold the Right arrow for two (2) seconds to save this setting.
8. Press the Up and Down arrows together to return the flow meter to normal
operation.
Options
Menu
Function
Option Description
A Selects totalizer reset options:
Lock: on (enabled)
Lock: off (disabled)
B Selects display averaging:
off = 100 mslo
low = τ = 700ms
hi = τ = 3s
C Selects display decimal (****. to **.**)
D Adjusts 4 mA output (3.9 to 4.1 mA)
E Adjusts 20 mA output (19.8 to 21.0 mA)
To Next Page
