FLOW METERS
Review Flow Meter Calibrate Menu
7-144 Aquastorm™ Series Options Guide Rev. 1
7
Menu Functions The following table identifies flow meter calibrate menu functions.
Procedure Review the Options menu as follows:
1. Press the flow meter Up and Down arrows at the same time.
2. Hold for two (2) seconds to display the Calibrate menu.
3. To access the calibration settings, press the Up arrow three (3) times then
press the Down arrow one (1) time.
4. Press the Up or Down arrow to locate the K-factor screen.
5. Press the Right arrow to view the current K-factor.
6. Use the Up and Down arrows to set the K-factor to read 270.00.
7. Press and hold the Right arrow for two (2) seconds to save this setting.
8. Repeat Step 4. through Step 7. to set the K-total factor to 270.00.
9. Press the Up and Down arrows together to return the flow meter to normal
operation.
Options
Menu
Function
Option Description
A Selects display contrast [four (4) levels]
B Sets flow units label and time base
[gallons per minute (gpm)]
C Sets flow K-factor (0.01 to 99999)
D Sets totalizer units (for label purposes only)
E Sets totalizer K-factor (0.01 to 99999
F Sets 4 mA setpoint
GSets 20 mA setpoint
H Sets user defined date
ATTENTION
Flow and totalizer K-factors are independent of each
other. These K-factors represent the number of
pulses generated by the flow meter for each
engineering unit measured.
