RESISTIVITY MONITOR
Overview
2-9317-600-00-0 Aquastorm™ Series Options Guide 10-189
Photograph Figure 10–2 shows the lower floor bulkhead and plumbing lines of the
Aquastorm™ final rinse section, identifies the resistivity probe location, and
shows a close-up view of the resistivity probe.
Figure 10–2
Final Rinse Plumbing
Resistivity Probe
Flow Meter
