BLOWER ENHANCEMENTS
Functional Description
16-304 Aquastorm™ Series Options Guide Rev. 1
16
Figure 16–2 shows the top of an Aquastorm system and identifies the 304.8 mm
(12 in.) air intake port and standard dryer section exhaust port locations.
Figure 16–2
Blower Dryer
Standard Exhaust Port
Machine Exit End
Air Intake Port
Rear Section
