BLOWER ENHANCEMENTS
Software Configuration
16-316 Aquastorm™ Series Options Guide Rev. 1
16
Procedure Configure the blower fail detect as follows
1. Press the menu key on the LCD interface keypad to access configuration
screen #1.
2. Press the page down key twice to display configuration screen #3.
3. Press the enter key to toggle to YES and indicate the blower fail detect is
installed.
4. Press the enter key to accept the configuration.
5. Press the Menu key to accept the changes.
6. The update screen displays and the system returns to the main menu.
7. Configure the system alarms to recognize the blower fail detect.
Diagrams Figure 16–9 displays Configuration Screen #4. Figure 16–10 shows the alarm
process screen.
Figure 16–9
Figure 16–10
ALARM_PROCESS SET
WATCH_DOG TEST
PRE_WASH_FLOW YES
FINAL_RINSE_FLOW YES
FLOW_UNITS GPM
GAS_HEAT_WASH NO
GAS_HEAT_RINSE NO
MACH_LEN_PCT 50
ALARM BAND ACTION REALARM
CONV 1.0 FPM WARNING 05 MIN
WASH 10 F SHUTDOWN 05 MIN
CHEM 10 F IGNORE 05 MIN
RINSE 10 F SHUTDOWN 05 MIN
BLWR 10F WARNING 05 MIN
SAPON SHUTDOWN 05 MIN
BLWR_FAIL SHUTDOWN 05 MIN
To Next Page
