Tektronix DSA70000/B Series Programmer's Manual

Command Groups
Command
Description
TRIGger:{A|B}:EDGE:SLOpe:CH<x> Sets or returns the slope for the edge trigger
for the channel
TRIGger:{A|B}:EDGE:SOUrce Sets or r eturns the source for the edge trigger
TRIGger:{A|B}:LEVel Sets or returns the level for the trigger
TRIGger:{A|B}:LEVel:CH<x> Sets or returns the level for the trigger for the
channel
TRIGger:{
A|B}:EDGE?
bbvannReturns the source, coupling and
source for
the edge trigger
TRIGger:
{A|B}:EDGE:COUPling:CH<x>
Sets or qu
eries the type of coupling for the A
or B trigger for the specified channel
TRIGger:{A|B}:LOGIc:CLAs s Sets or returns the type of trigger logic
TRIGger:{A|B}:LOGIc:F U NC tion Sets or returns the logical combination of the
input channels for the logic trigger
TRIGger:{A|B}:LOGIc:INPut? Returns the logic trigger input expected for
channe
l1,2,and3
TRIGg
er:{A|B}:LOGIc:INPut:CH<x >
Sets o
r queries the logical input for the logic
trigger channel specified by x
TRIGger:{A|B}:LOGIc:PATtern:INPut:CH<x> Sets or returns the logic pattern trigger input
for the indicated channel
TRIGger:{A|B}:LOGIc:PATtern:WHEn Sets or returns the condition for generating
the l
ogic pattern trigger
TRI
Gger:{A|B}:LOGIc:PATtern:WHEn:
LESSLimit
Set
s or returns the maximum time that
the selected pattern may be true and still
generate a logic pattern trigger
TRIGger:{A|B}:LOGIc:PATtern:WHEn:
MO
RELimit
Sets or returns the minimum time that
th
e selected pattern may be true and still
generate a logic pattern trigger
TRIGger:{A|B}:LOGIc:PATtern? Returns the conditions for generating a logic
pattern trigger
TRIGger:{A|B}:LOGIc:S ETH o ld:C LOC k:
EDGE
Sets or returns the clock edge polarity for
setup and hold triggering
TRIGger:{A|B}:LOGIc:S ETH o ld:C LOC k:
SOUrce
Sets or returns the clock source for the logic
trigger setup and hold input
TRIGger:{A|B}:LOGIc:S ETH o ld:C LOC k:
THReshold
Sets or returns the clock voltage threshold for
setup and hold trigger
TRIGger:{A|B}:LOGIc:S ETH o ld:C LOC k:
THReshold:CH<x>
Sets or returns the clock voltage threshold for
setup and hold trigger for the channel
TRIGger:{A|B}:LOGIc:S ETH o ld:C LOC k?
Returns clock edge polarity, voltage threshold
and source input for setup/hold triggering
oh good
TRIGger:{A|B}:LOGIc:S ETH o ld:D ATa:
SOUrce
Sets or returns the data source for the setup
and hold trigger
DPO7000, DPO70000/B and DSA7000/B Series Programmer Manual 2-57
