Tektronix DSA70000/B Series Programmer's Manual

Command Groups
Command
Description
TRIGger:{A|B}:LOGIc:SETHold:DATa:
THReshold
Sets or returns the data voltage threshold for
setup and hold trigger
TRIGger:{A|B}:LOGIc:SETHold:DATa:
THReshold:C
H<x>
Sets or returns the data voltage threshold for
setup and hol
d trigger for the channel
TRIGger:{A
|B}:LOGIc:SETHold:DATa?
Returns the voltage threshold and data
source for t
he setup/hold trigger
TRIGger:{A
|B}:LOGIc:SETHold:HOLDTime
Sets or retu
rns the hold time for the setup
and hold v iolation triggering
TRIGger:{A|B}:LOGIc:SETHold:QUAlify Sets or returns the setup and hold violation
trigger qualifications
TRIGger:{A|B}:LOGIc:SETHold:SETTime Sets or returns the setup time for setup and
hold viol
ation triggering
TRIGger
:{A|B}:LOGIc:SETHold?
Returns clock edge polarity, voltage threshold
and sour
ce; data voltage threshold and
source; and setup/hold times for setup and
hold violation triggering
TRIGger:{A|B}:LOGIc:STATE:INPut:CH<x> Sets or returns the slope for indicated channel
of the l
ogic state trigger
TRIGg
er:{A|B}:LOGIc:STATE:WHEn
Sets o
r returns the c ondition for generating a
logic state trigger
TRIGger:{A|B}:LOGIc:STATE? Returns the data input and trigger criteria for
the logic state trigger
TRIGger:{A|B}:LOGIc:THReshold:CH<x> Sets or returns the logic state trigger
thre
shold voltage for the specified channel
TRI
Gger:{A|B}:LOWerthreshold:CH<x>
Set
s or returns CH<x> lower trigger level for
TRIGger: LVLSrcpreference
TRIGger:{A|B}:LOGIc:THReshold? Returns the threshold voltage for all channels
in logic trigger
TRIGger:{A|B}:PULse:CLAss Sets or returns the type of pulse on which
t
o trigger
T
RIGger:{A|B}:PULse:GLItch:POLarity
S
ets or returns the polarity for the pulse glitch
trigger
TRIGger:{A|B}:PULse:GLItch:POLarity:
CH<x>
Sets or returns the polarity for the A or B
pulse glitch trigger for the channel
TRIGger:{A|B}:PULse:GLItch:QUAlify Sets or returns the glitch trigger qualifications
TRIGger:{A|B}:PULse:GLItch:TRIGIF Sets or returns the acceptance or rejection of
pulse glitch trigger, based on width
TRIGger:{A|B}:PULse:GLItch:WIDth Sets or returns the width of the A pulse glitch
trigger
TRIGger:{A|B}:PULse:GLItch?
Returns the current A glitch pulse trigger
parameters
TRIGger:{A|B}:PULse:RUNT:POLarity Sets or returns the polarity for the pulse runt
trigger
2-58 DPO7000, DPO70000/B and DSA7000/B Series Programmer Manual
