Setup Menu
Pocket-3D Reference Guide
2-10
On the radio setup dialog box, set the following parameters
(
Figure 2-15):
• Radio type – the type of radio.
• Port – the port used for radio connection.
• Baud rate – the speed of communication rate between the radio
unit and the GPS+ receiver.
• Format – current GPS+ systems are capable of either CMR or
RTCM corrections.
• Configure – changes the radio channel; press to display the
channel configuration dialog box (
Figure 2-15). Select the
desired channel and the corresponding Frequency displays.
• Set – press to apply the radio channel parameters.
• Next – press to display the GPS receiver settings dialog box
(
Figure 2-16 on page 2-11).
Figure 2-15. Radio Setup and Channel Configuration Dialog Boxes
On the GPS receiver settings dialog box (Figure 2-16 on page 2-11)
do the following and press Finish to connect to the GPS receiver.
• Use co-op tracking – if enabled, allows higher efficiency of
multipath reduction. This option is only valid for a base station
receiver (non-moving).
• Use multipath reduction – if enabled, reduces multiple reflections
from nearby objects.
