24-Port 10/100Mbps Layer 2 Switch w/ 4 Gigabit Ports and 2 Shared Mini-GBIC Slots

15-6

Example

switch#show ip route summary

Route Source Routes

connected 0

static 0

rip 0

bgp 0

ospf 0

Total 0

Command History

Version

History

1.00.001

This command was introduced.
