TRENDnet TL2-E284 - Page 251

24-Port 10/100Mbps Layer 2 Switch w/ 4 Gigabit Ports and 2 Shared Mini-GBIC Slots
35-7
Syntax Description
ip
Matching all IP packets.
ospf
Matching all OSPF packets.
pim
Matching all PIM packets.
protocol-type
(1-255)
Matching packets with specific protocol type.
any
Matching packet with any source IP address.
host
src-ip-address
Matching packet with a specific source IP address.
src-ip-address
mask
Matching packet with a range of source IP address. For
example 172.17.5.1 with mask 255.255.255.0 means
172.15.5.0~255.
any
Matching packet with any destination IP address.
host
dest-ip-address
Matching packet with a specific destination IP address.
dest-ip-address
mask
Matching packet with a range of destination IP address.
For example 172.17.5.1 with mask 255.255.255.0 means
172.15.5.0~255.
tos value (0-7)
Matching packets with specific ToS value.
dscp value
(0-63)
Matching packets with specific DSCP type.
tcp
Matching all TCP packets.
udp
Matching all UDP packets.
anyport
Matching packets with any L4 source port.
src-port
(1-65535)
x8000 ~ xFFFF
Matching packets with a specific L4 source port.
dest-port
(1-65535)
x8000 ~ xFFFF
Matching packets with a specific L4 destination port.
ack
Macthing packets with a TCP acknowledge flag
ack-not
Macthing packets with a TCP acknowledge-not flag
rst
Macthing packets with a TCP reset flag
rst-not
Macthing packets with a TCP reset not flag
Command Modes
Extended IP Access List Configuration Mode
Example
switch(config-ext-nacl)# deny ip any any tos 7
Command History
Version
History
1.00.001
This command was introduced
