TRENDnet TL2-E284 - Page 31

24-Port 10/100Mbps Layer 2 Switch w/ 4 Gigabit Ports and 2 Shared Mini-GBIC Slots
5-13
reset to defaults. Requires a manual device reboot for changes to take effect.
Please reference the default NV-RAM parameters below.
 Default IP Address : 192.168.10.200
 Default Subnet Mask: 255.255.255.0
 Default IP Address Config Mode: Manual
 Default IP Address Allocation Protocol : DHCP
 Default Interface Name: Fa0/1
 Default RM Interface Name: NONE
 Config Restore Option: No restore
 Config Save Option: Startup save
 Config Save IP Address: 0.0.0.0
 Config Save Filename: iss.conf
 Config Restore Filename: iss.conf
 PIM Mode: Sparse Mode
 IGS Forwarding Mode: MAC based
 CLI Serial Console: Yes
 SNMP EngineID: 80.00.08.1c.04.46.53
 SNMP Engine Boots: 1
 Default VLAN Identifier: 1
Erase Startup-Config: Reset the all device configuration to default settings.
Note: This will reset the startup device configuration to default. Any previously
saved configuration files in flash memory will NOT be deleted or erased. After
a device reboot or power cycle, the default device configuration will be loaded
to the device. Requires a manual device reboot for changes to take effect.
Erase Flash File: Reset the specified configuration file in the device‟s flash
memory to default settings.
Note: This will not reset the device‟s active configuration.
File Name
Specify the file name of the local configuration file.
Click Apply to submit the changes and the Reset button will clear the information.
Firmware Upgrade
Parameter
Description
HTTP
Firmware Upgrade
Click Browse to locate the firmware file on the local hard drive and select it.
TFTP
Firmware Upgrade
TFTP Server IP Address: Specify the IP address of the TFTP server.
TFTP firmware file name: Specify the filename of the firmware file.
